1-Phasen Steuertransformatoren

1-Phasen Steuertransformatoren

1-Phasen Steuertransformatoren

für den Steuerungsbau, als Spannungsanpassung oder zur galvanischen Trennung

  • Primärspannung 230/400V +/- 15V
  • Sekundärspannung 230V oder 24V
  • Norm: EN 61558-2-4 / -6 / -2
  • Schraubklemmen
  • Befestigungswinkel
  • nicht kurzschlussfest

Unsere Standard Transformatoren sind kurzfristig ab Lager lieferbar.

Art-Nr.P (VA)Pri (V)Sek (V)AxBxC (mm)DxE (mm)G (kg)
1010530230-400V/+-15V230V60x78x7144x490.75
1010660230-400V/+-15V230V84x75x9164x521.5
10107100230-400V/+-15V230V84x90x9164x641.98
10108160230-400V/+-15V230V96x85x10284x652.25
10109200230-400V/+-15V230V96x91x10284x732.74
10110250230-400V/+-15V230V96x105x10284x903.51
10111315230-400V/+-15V230V120x90x12090x734
10112400230-400V/+-15V230V120x105x12090x855
10113500230-400V/+-15V230V120x125x12090x1066.6
10114630230-400V/+-15V230V150x110x160122x907.7
10115800230-400V/+-15V230V150x130x160122x1069.8
101161000230-400V/+-15V230V150x155x160122x13412.7
101171300230-400V/+-15V230V174x148x200135x12116
101181600230-400V/+-15V230V174x188x200135x14121
101192000230-400V/+-15V230V192x154x220155x12923
101202500230-400V/+-15V230V192x182x220155x15727
1012130230-400V/+-15V24V60x78x7144x490.75
1012260230-400V/+-15V24V84x75x9164x521.5
10123100230-400V/+-15V24V84x90x9164x642
10124160230-400V/+-15V24V96x85x10284x652.25
10125200230-400V/+-15V24V96x91x10284x732.8
10126250230-400V/+-15V24V96x105x10284x903.51
10127315230-400V/+-15V24V120x90x12090x734
10128400230-400V/+-15V24V120x105x12090x855
10129500230-400V/+-15V24V120x125x12090x1066.8
10130630230-400V/+-15V24V150x110x160122x907.7
10131800230-400V/+-15V24V150x130x160122x1069.8
101321000230-400V/+-15V24V150x155x160122x13412.7
101331300230-400V/+-15V24V174x148x200135x12116
101341600230-400V/+-15V24V174x188x200135x14121
101352000230-400V/+-15V24V192x154x220155x12926
101362500230-400V/+-15V24V192x182x220155x15730
